9 Element 9000 watt - 10" Hot Zone - 17" Overall Length

$1,123.20
CALL FOR AVAILABILITYCALL FOR AVAILABILITY
SKU
PRT-9TSS-10-17
9,000 watt, 9 tube over the side heater. 316 stainless steel 10" hot zone and 17" overall length. Thermal protection options. 36" wire with conduit. 240 or 480 volt. 1 or 3 phase

6 Element Tubular Over The Side Heater

  • 9 heavy wall 316 stainless steel sheaths.
  • Watt densities up to 40 watts/square inch (6.2 w/cm²).
  • Vapor resistant, flame retardant polypropylene terminal enclosure with 3 ft (.9m) flexible PVC liquid tight conduit.
  • Grounded construction and built in thermal protector. Replaceable P1 protector standard for solutions up to 180°F(82°C).
  • Certification: cULus (except steel and 600 volts)
SPECIFICATIONS
  • 9,000 watts
  • 240 or 480 volts
OPTIONS AVAILABLE (CONSULT FACTORY)
  • Resettable thermal protectors require additional control components
  • Custom configurations and lengths
  • Custom wire and conduit lengths
